Quartz CNC Machining Center
Ref: GSY-3015ATC Marca: GANGER
$ 75,000.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
Características
Quartz CNC Machining Center GSY-3015ATC
Machine feature:
1. With linear type auto tool changer,
12 tools, convenient and high efficiency.
2. Do cutting, drilling holes, edge
profiling and polishing, finish one countertop at one time, high efficiency.
3. Humanized control system, easy to
operate.
4. Whole steel structure machine body
ensuring high stability.
Technical parameters | |
Model | GSY-3015ATC |
X/Y/Z Axis working size | 3000*1500*430mm |
Working table | Aluminum profile with T-slot and water tank |
X/Y/Z Axis transmission | X/Y Axis helical Gear and rack, Z Axis Ball screw |
spindle power | ATC spindle 7.5KW(optional) |
Max spindle speed | 8000rpm |
ATC type and capacity | Linear ATC, 12 tools |
Driver motor | servo |
Control system | GANGER |
Gross weight | 3500KGS |
Applicable
industry and applicable materials
Applicable
industries: Widely used in CNC processing and production of basins, cabinet
countertops, bathroom countertops, bar counters, kitchen countertops,
washstands, marble walls, dining tables, coffee tables, window sills, door
pockets, etc.
Applicable
materials: widely used in granite, quartz stone, artificial stone, marble and
other stone.
