Two Heads CNC Machining Center for Cou
Ref: GSY-3015ATC Marca: GANGER
$ 75,000.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
Características
Two Heads CNC Machining Center for Countertops GSY-3015ATC
Machine
feature:
1. Double
ATC spindle work simultaneously.
2. The
spindles can work independently.
3. Linear
type auto tool changer, double tool magazines, 12 tools, high efficiency.
4. Do
cutting, drilling holes, edge profiling and polishing, finish two countertops
simultaneously.
5. International
control system, global warranty.
|
Technical
parameters |
|
|
Model |
GSY-3015ATC |
|
X/Y/Z Axis working size |
3000*1500*430mm |
|
Working table |
Aluminum profile with T-slot and water tank |
|
X/Y/Z Axis transmission |
X/Y Axis helical Gear and rack, Z Axis Ball screw |
|
spindle power |
ATC spindle 7.5KW(optional) |
|
Max spindle speed |
8000rpm |
|
ATC type and capacity |
Linear ATC, 12 tools |
|
Driver motor |
servo |
|
Control system |
Siemens |
|
Gross weight |
4000KGS |
Applicable
industry and applicable materials
Applicable
industries: Widely used in CNC processing and production of basins, cabinet
countertops, bathroom countertops, bar counters, kitchen countertops,
washstands, marble walls, dining tables, coffee tables, window sills, door
pockets, etc.
Applicable
materials: widely used in granite, quartz stone, artificial stone, marble and
other stone.
