4 Axis CNC Bridge Cutting Machine
Ref: GQ-3220C Marca: GANGER
$ 75,000.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
Características
4 Axis CNC Bridge Cutting Machine GQ-3220C
Machine features
1.XYZC four axis, C axis 0 to 135
degree automatic rotation, cutting in the direction of X and Y axis.
2.PLC control system, input operating
parameters on the control panel, and the cutting process is automated and
programmed.
3.By infrared ray to confirm the
position of the workpiece.
4.whole steel structure machine body
ensuring high stability.
5.Running stability, high precision,
high speed.
6.Compact and rational design, small
size machine, convenient to handle and move.
Technical parameters | |
Model | GQ-3220C |
X/Y/Z Axis working size | 3200*2000*200mm |
Diameter of blade | 350mm |
Working table size | 3200x2000mm |
Spindle power | 11KW |
Max spindle speed | 2840rpm (Optional, adjustable) |
C axis rotation angle | 00 - 1350 |
Control system | GANGER |
Gross weight | 4500KGS |
Applicable industry & material Applicable industry: rock slab application industry,
fabricated building materials industry, home decoration materials industry,
cutting marble, artificial stone, quartz stone and other materials.
Applicable material: rock slab, ceramic plate,
quartz stone, marble, etc.
