Características

Practical wood engraving machine SH-1325

Machine features:

1.Chinese famous brand Spindle: high torque ,low noise,long using life.

2.Main machine parts can adopt imported brands for your pursue of high quality.

3.Large compatibility. CAD/CAM designing software like Type 3/ArtCAM/Castmate /wentai and so on

4.Whole machine of high rigidity steel structure,ensuring equipment’s steadiness and bearing capability of high pressure.

5.Professional human control system shows advantages as continuing carving when occurring breakpoint ,off power, processing time can be forecast, back to the origin, and automatic correction function.

Technical parameters
Model	SH-1325	SH-1530
X/Y/Z Axis working size	1300*2500*200mm	1500*3000*200mm
Feeding height	200mm
Working table	Aluminum profile with T slot/Vacuum absorption table/Vacuum table combined with T slot
X/Y/Z Axis transmission	X/Y Axis Helical Gear and rack ,Z Axis Ball screw
Spindle power	Water-cooled spindle 4.5kw
Max spindle speed	18000rpm
Collet/Blade diameter	ER25(2-16mm)
Driver motor	Servo motor
Control system	DSP system
Gross weight	1500-2000KGS

Applicable industry and material:

Applicable industry: wood furniture ,wooden crafts processing industry, suitable for large panel cutting,large relief carving products and large carpentry engraving.

Applicable material: solid wood panel, artificial board, Acrylics ,PVC, MDF,etc.

---
