4-axis Wood CNC Router
Ref: SH-1530R Marca: GANGER
$ 75,000.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
Características
4-axis Wood CNC Router SH-1530R
Machine features
1. Four-axis linkage, the spindle can
swing ±90 degrees, special for engraving and cutting convex, concave
and irregular workpieces.
2. High quality spindle with large
torque, low noise and long service life.
3. The main spare parts are imported
accessories to meet your requirements for the high quality.
4. Humanized control system, easy to
operate.
5. The whole steel structure machine
body ensures high stability.
Technical parameters | |||
Model | SH-1325R | SH-1530R | SH-2030R |
X/Y/Z Axis working size | 1300*2500*500mm | 1500*3000*500mm | 2000*3000*500mm |
Working table | Aluminum profile with T slot/Vacuum absorption table | ||
X/Y/Z Axis transmission | X/Y Axis Helical Gear and rack ,Z Axis Ball screw | ||
Spindle power | Air-cooled spindle 6KW | ||
Collet/Blade diameter | ER32 (2-20mm) | ||
Driver motor | Servo motor | ||
Control system | 4 axis control system | ||
Applicable industry and materials:
Applicable industries: For routing,
engraving, carving relief and cutting for furniture industry, wooden handicraft
processing industry, automotive stamping foam molds, advertising and other
industries.
Applicable materials: various wood, acrylic, PVC, MDF, plexiglass, rubber materials,
foam, etc.
