CNC Machining Center with Auto-loading
Ref: GM6-1224ATC Marca: GANGER
$ 75.00
Space for info
Lorem ipsum dolor sit amet, consectetur adipisicing elit. Ipsam, nisi.
Características
CNC Machining Center with Auto-loading/unloading GM6-1224ATC
Machine Features:
1. Highly automated nesting
solution with automatic loading and unloading system. The complete work cycle
of loading, nesting, drilling and unloading is carried out automatically, which
results in maximum productivity and zero down time.
2. Humanizing design of
the machine control interface,very simple
to operate, requiring only minimal training of operator, do not
need specialized operationtechnical personnel, high efficiency.
3. World's first class components--Italian high-frequency electro
spindle, Taiwan SYNTECcontrol system, German servo motors and
drivers, high precision planetary gear reducers, etc,stable
performance and long service life.
4. The world's leading vacuum table,
high adsorptioncapacity, canbe strong adsorption of materials of different
sizes, density, nodeformation.
5. Truly versatile--nesting, routeing, vertical
drilling, engraving,side milling and edge grinding all in one. It is
well-suited for panel furniture, office furniture, cabinets production.
Technical parameters | |
Model | GM6-1224ATC |
X/Y/Z Axis working size | 1224*2440*200mm |
Working table | Vacuum absorption table |
X/Y/Z Axis transmission | X/Y Axis helical Gear and rack, Z Axis Ball screw |
Spindle power | Italy HSD Air-cooled ATC spindle 9.0kw/12.0kw |
Max spindle speed | 24000rpm |
Collet/Blade diameter | ISO30 |
ATC type and capacity | Disc type ATC, 12 tools |
Driver motor | Servo motor |
Control system | Taiwan SYNTEC |
Gross weight | 3500KGS |
Applicable industry and material:
Applicable industry: wood furniture ,
panel furniture,wooden crafts processing industry, suitable for large panel
cutting,large relief carving products and large carpentry engraving.
Applicable material: solid wood panel,
MDF.
