Características

Stone Column Engraving Machine GS-2020

Machine features:

1. Specialized stone Spindle,features: high torque,low noise, long using life.

2. Two heads hold four spindles: high efficient ,high precision

3. Main machine parts can  adopt imported brands for your pursue of high quality.

4. Large compatibility. CAD/CAM designing software like Type 3/ArtCAM/Castmate /wentai and so on

5. Whole machine of high rigidity steel structure,ensuring equipment’s steadiness and bearing capability of high pressure.

6.Professional human control system shows advantages as continuing carving when occurring breakpoint,oof power,processing time can be forecast ,back to origin, and automatic correction funtion.



Technical parameters
Model	GS-2020
Y/Z Axis working size	2000*100mm
Feeding height	200mm
Y/Z Axis transmission	Y Axis helical Gear and rack, Z Axis Ball screw
Spindle power	Water-cooled spindle 3.7KW/5.5KW/6KW specialized stone spindle
Max spindle speed	0-24000rpm,ER20(2-13)
Rotary	4 sets
Driver motor	Servo motor
CNC Control system	CNC Specific System
Gross weight	2000KGS

Applcable industry&Material

 Applicable industry:widely used in stone cylinder,column engraving industry ,craft processing and building material industry

Applicable material: stone , artificial marble, brass

---
