Características

Practical Multi-head stone engraving machine GS-1825-2-4

Machine features:

1.Specialized stone Spindle features: high torque ,low noise,long using life.

2. Main machine parts can adopt imported brands for your pursue of high quality.

3. Large compatibility. CAD/CAM designing software like Type 3/ArtCAM/Castmate /wentai and so on

4. Whole machine of high rigidity steel structure,ensuring equipment’s steadiness and bearing capability of high pressure.

5. Professional human control system shows advantages as continuing carving when occurring breakpoint ,off power, processing time can be forecast, back to the origin, and automatic correction function.

6. Process 4 sets of workpieces at single process to improve production

Technical parameters
Model	GS-1825-2-4
X/Y/Z Axis working size	1800*2500*300mm
Feeding height	300mm
X/Y/Z Axis transmission	X/Y Axis helical Gear and rack, Z Axis Ball screw
Spindle power	Water-cooled spindle 3.7KW/5.5KW/6KW specialized stone spindle
Spindle speed/collet	0-24000rpm,ER20(2-13)
Working table	Aluminum profile with T slot,with water tank
Driver motor	Servo motor
CNC Control system	CNC Specific System
Gross weight	2000KGS

Applicable industry & material

Applicable industry: widely used in large stone panel engraving industry,craft processing

and building material industry.

Applicable material: stone,artificial marble,glass,brass,aluminum etc. Soft metal plate

---
