Características

Practical stone engraving machine GS-1825-2

Machine features:

1.Specialized stone Spindle features: high torque ,low noise,long using life.

2. Two heads hold two spindles,high efficient,high precision.

3. Main machine parts can adopt imported brands for your pursue of high quality.

4. Large compatibility. CAD/CAM designing software like Type 3/ArtCAM/Castmate /wentai and so on

5. Whole machine of high rigidity steel structure,ensuring equipment’s steadiness and bearing capability of high pressure.

6. Professional human control system shows advantages as continuing carving when occurring breakpoint ,off power, processing time can be forecast, back to the origin, and automatic correction function.

Technical parameters
Model	GS-1825
X/Y/Z Axis working size	1800*2500*300mm
Working table	Aluminum profile with T slot ,water-tank
X/Y/Z Axis transmission	X/Y Axis helical Gear and rack ,Z Axis Ball screw
Spindle power	Water-cooled spindle 5.5kw
Collet/Blade diameter	ER 25 (2-16mm)
Driver motor	Servo motor optional
Control system	German Siemens optional
Gross weight	2.0t

Applicable industry and material:

Applicable industry: widely used in large stone panel engraving industry,craft processing

and building material industry.

Applicable material: stone,artificial marble,glass,brass,aluminum etc. Soft metal plate

---
